What Is the KTPLBOND-701 Milk Analyzer?
The KTPLBOND-701 is an Android-based smart milk analyzer and milk collection system from KTPL India. It brings together ultrasonic milk composition testing, digital milk weighing support, data management and thermal receipt printing in one integrated setup.
This type of system is intended for workflows where a collection operator needs to weigh a milk delivery, test a sample, save the readings and provide a printed receipt. Combining these steps can help keep collection records organised and make the transaction easier for the operator and supplier to review.
Which Milk Parameters Does KTPLBOND-701 Measure?
According to the product specifications published by KTPL India, the KTPLBOND-701 measures FAT, SNF, density, protein and added water. The listed measurement ranges are FAT 0.5%–12%, SNF 6%–12%, density 1.0260–1.0330 g/cm³, protein 2%–6% and added water 0%–60%. These are the stated ranges for this model, not a guarantee that every sample will fall within them.
FAT represents the fat content of the milk. SNF means solids-not-fat and broadly covers milk solids other than fat, including components such as protein, lactose and minerals. Density provides another composition-related reading, while added-water results should be interpreted in the context of sample quality, calibration and the dairy’s quality-control procedure. An analyzer reading should not replace confirmatory laboratory testing where a dispute or formal compliance decision requires it.
KTPLBOND-701 Technical Specifications
Measurement technology: Ultrasonic milk analyzer. Display: Android touch screen. Sample volume: 50 ml per test. Power input: DC 12V. Printer: integrated thermal receipt printer. Connectivity: Wi-Fi, GSM, USB and LAN, as listed on the product page.
The published specifications also list a digital weighing indicator with digital calibration, a heavy-duty MS/SS platform and an RS232 communication interface. The stated weighing-indicator accuracy is ±0.02% F.S. (full scale). Because this is a specification for the weighing indicator, it should not be confused with a milk-composition accuracy figure. Confirm the exact supplied configuration and applicable technical documentation with KTPL before purchase.
How Does an Ultrasonic Milk Analyzer Work?
An ultrasonic milk analyzer sends sound waves through a milk sample and measures the response. The instrument uses its measurement system and calibration to estimate selected composition parameters. The displayed results depend on correct sample handling, suitable calibration and operation according to the manufacturer’s instructions.
For consistent routine testing, mix the sample properly before taking the test portion, follow the model’s recommended sample-handling procedure, keep the sample path clean and use the appropriate calibration for the milk type and operating conditions. Do not assume that every ultrasonic analyzer uses the same sample volume, test time or parameter range; these details vary by model.
How the Milk Collection Workflow Fits Together
A typical collection workflow can include receiving the milk, weighing it, taking a representative sample, running the quality test, saving the result and printing a receipt. The KTPLBOND-701 is designed to bring weighing support, testing, data handling and receipt printing together in one system.
Digital records and a printed slip can support traceability by making transaction information easier to check later. The actual payment formula, farmer account setup, report fields and software integrations depend on the dairy’s operating process and the configuration supplied. Confirm these workflow details during a product demonstration.
Android Interface, Connectivity and Receipt Printing
The Android touch interface is intended to support day-to-day operation and data management. The product page lists Wi-Fi, GSM, USB and LAN connectivity, which can be useful when a collection point needs to transfer records or connect compatible equipment and systems. The available functions can depend on software version, network availability and the final configuration.
The built-in thermal printer is designed to print collection receipts or test slips. Before ordering, ask what information can appear on the receipt, whether the required language and report format are supported, and what consumables are needed. Also confirm whether any third-party software, SIM/data plan or integration work has an additional cost.
Who Can Use the KTPLBOND-701?
The published applications include dairy cooperatives, milk collection centres, private dairy plants, chilling centres, dairy farms, farmer-producer organisations (FPOs), NGOs and milk-testing laboratories. It may be worth evaluating where weighing, testing and receipt printing are currently separate steps and whether an integrated unit would fit the operation.
The best configuration depends on daily sample volume, the milk types being tested, the required reports, connectivity at the site, staff training and service availability. Ask for a demonstration using your intended workflow rather than choosing only by the number of listed features.
What to Check Before Buying the KTPLBOND-701
1. Confirm the required parameters. Check that the published ranges and outputs meet your procurement or quality-control needs. 2. Review the weighing setup. Confirm platform size, load-cell compatibility, calibration and installation requirements. 3. Ask for a live demonstration. Test the full process from weighing to printed receipt.
4. Confirm data and connectivity requirements. Ask which reports, languages, network connections and software integrations are included. 5. Clarify service terms. Request written details on warranty, calibration support, training, maintenance and spare parts. 6. Get a configuration-specific quotation. Confirm taxes, delivery, installation, accessories and any recurring connectivity or software charges before comparing offers.
KTPLBOND-701 Price in India: How to Get a Reliable Quote
A verified current price should be requested directly from KTPL because the final quotation can depend on the supplied configuration, accessories, delivery and service terms. This guide does not state an unverified fixed market price. When comparing quotes, check that each supplier is pricing the same setup and that installation, training, warranty and taxes are clearly described.
For product-specific information, visit the KTPLBOND-701 product page or use KTPL India’s quotation enquiry page to ask about current availability, configuration and delivery.
Cleaning, Calibration and Routine Care
Follow the cleaning and maintenance procedure supplied for the exact unit. Clean the sample path as instructed, avoid leaving milk residue inside the system and handle the sample consistently from test to test. Use the recommended calibration procedure and keep records of calibration checks and maintenance where appropriate.
If results appear inconsistent, check sample mixing, sample condition, operating procedure and calibration before relying on a single reading. Contact the supplier or qualified service team if the issue persists. Never change calibration values simply to force a preferred result.
Explore the KTPLBOND-701 Product Details
To review the current product information, specifications and enquiry options, visit the KTPLBOND-701 Smart Milk Analyzer page. Share your daily collection volume, milk types, receipt needs and connectivity requirements when requesting a quotation so the recommended setup can be checked against your actual workflow.
