KTPL Instruments Pvt. Ltd.
KTPLBOND-701 is an Android-based smart milk analyzer and milk collection system that combines ultrasonic milk testing, digital milk weighing, data management and instant thermal receipt printing in one integrated unit.
KTPLBOND-701 BT is a Bluetooth-enabled milk collection and quality analysis system that combines ultrasonic milk testing, high-accuracy weighing support, digital record management, mobile app viewing and instant thermal receipt printing.
View ProductKTPLBOND-701 is a complete smart milk collection and quality analysis system designed for dairy cooperatives, milk collection centers and modern dairy businesses.
The system integrates milk quality testing, digital weighing, Android-based data management and receipt printing to support fast, accurate and transparent milk collection operations.
It measures FAT, SNF, Density, Protein and Added Water and supports connected data handling through WiFi, GSM, USB and LAN interfaces.
| FAT | 0.5% – 12% |
| SNF | 6% – 12% |
| Density | 1.0260 – 1.0330 g/cm³ |
| Protein | 2% – 6% |
| Added Water | 0% – 60% |
| Technology | Ultrasonic Milk Analyzer |
| Display | Android Touch Screen |
| Sample Volume | 50 ML / Test |
| FAT Range | 0.5% – 12% |
| SNF Range | 6% – 12% |
| Density Range | 1.0260 – 1.0330 g/cm³ |
| Protein Range | 2% – 6% |
| Added Water | 0% – 60% |
| Connectivity | WiFi, GSM, USB, LAN |
| Printer | Thermal Receipt Printer |
| Power Supply | DC 12V Input |
| Capacity | Up to 180 Samples / Hour (Approx.) |
| Sample Volume | 50 ML / Test |
| Stirrer Timer | Adjustable 7 Sec. – 15 Sec. |
| Working Principle | Ultrasonic with Adjustable Frequency |
| Display | 7 Segment Digital Display, 10 mm Height |
| Key Buttons | Easy Operate Key Buttons |
| Calibration | Digital Calibration |
| Platform Type | Heavy Duty MS/SS Platform |
| Communication Port | RS232 Interface |
| Accuracy | ±0.02% F.S. |
| CPU | Quad Core Cortex-A35 |
| GPU | Mali-G31 GPU |
| Memory | On-board DDR3 2G high-speed dual channel RAM, expandable up to 4G |
| Built-in Storage | 8G / 16G Optional |
| High-Speed Storage | Maximum 128G Optional |
| Display Interface | HDMI connector, supports 1080 Pixels |
| Network Support | WiFi, 3G/4G, Mini-PCIe module slot; BT 4.2 optional |
| Touch Screen | Multipoint capacitive touch screen support |
| USB | USB 2.0 / USB-A |
| COM | 2 RS232 (TTL optional) / 1 debugging TTL port |
| GPIO | 4-way I/O optional |
| Power Supply | DC 12V Input |
| Cooling | Cooling Sheet |
| Working Humidity | 0% – 90% relative humidity, non-condensing |
| Working Temperature | 0°C – 60°C |
| Body | Stainless Steel Body |
KTPLBOND-701 measures FAT, SNF, Density, Protein and Added Water.
Yes. The milk analysis section uses ultrasonic milk analysis technology.
Yes. The system includes digital milk weighing support and a weighing indicator with digital calibration.
Yes. The system includes thermal receipt printing for milk collection slips and reports.
The system supports WiFi, GSM, USB and LAN connectivity.
It is designed for dairy cooperatives, milk collection centers, private dairy plants, chilling centers, dairy farms, FPOs, NGOs and milk testing labs.
The specified sample volume is 50 ML per test.
Use the Send Enquiry option to request the current quotation, configuration and delivery details from KTPL Instruments.
Contact KTPL Instruments for the current KTPLBOND-701 Smart Milk Analyzer Machine configuration, quotation, accessories and delivery details in India.
